Your position: Home > Backhoe Loader > Backhoe loader for sale

1/1

Backhoe loader for sale

Name: Backhoe loader for sale
Brand: CAMCO MALL
Price: 29735 USD
Availability: InStock

0.0 (0)

0 Sold

$29,735.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

Description
About Camco
Purchase Notes

The backhoe loader belongs to a kind of small multifunctional construction machinery, which is generally used for small projects after the completion of large projects. The backhoe loader with two busy ends is generally the loading end at the front and the digging end at the rear, because it can be equipped with a variety of attachments for flexible operations.
The backhoe loader belongs to a kind of small multifunctional construction machinery, which is generally used for small projects after the completion of large projects. The backhoe loader with two busy ends is generally the loading end at the front and the digging end at the rear, because it can be equipped with a variety of attachments for flexible operations.

The Main Performance Parameter of Backhoe Loader
Overall Operating Weight	8200KG	Final Reducer	Single Stage Final Reducer
Transport Dimension		Rated Loader of Axle	8/18.5t
LWH(mm)	6120×2410×3763
cab to ground mm	2900mm	Transmission System
Wheel base	2248mm	Torque Converter
Min. Ground Clearance	300mm	Model	YJ280
Bucket Capacity	1.0m3	Type	Single-stage Three Elements
Breakout Force	38KN	Max. Efficiency	84.4%
Loading Lifting Capacity	2500KG	Gearbox
Bucket Dumping Height	2742mm	Type	Fixed Shaft Power Transmission
Bucket Dumping Distance	925mm	Oil Pressure of Clutch	1373Kpa—1569 Kpa
Digging Depth	52mm	Gears	Two Gears Ahead, Two Gears Astern
Backhoe Capacity	0.3 m3	Max.Speed	30Km/h
Max. Digging Depth	4082mm	Tyre
Swing Angle of Excavator Grab	190o	Model	14-17.5/19.5L-24
Max. Pulling Force	39KN	Pressure of Front wheel	0.55Mpa
Engine		Pressure of Back Wheel	0.223Mpa
Model	YC4A105Z-T20	Brake System
Type	In-Line Direct injection Four-Stroke and Injection Combustion Chamber	Emergency Brake	Operation Power Implementing brake
Cylinder-Inside Diameter*Stroke	4-108×132		Manual Operation Power Terminating Brake
Rated Power	75KW	Service Brake	Air Over Oil Caliper Brake
Rated Speed	2200r/min		External Type
Min. Fuel Consumption	≤230g/km.h		Self-regulation
Max.Torque	≥400N.M		Self-balance
Displacement	4.837L	Hydraulic System
Steering System		Digging Power of Excavator Grab	46.5KN
Model of Steering Device	BZZ5-250	Digging Power of Dipper	44KN
Steering Angle	±36 o	Bucket Lifting Time	6．8S
Min. turning radius	6581mm	Bucket Lowering Time	3.1S
Pressure of the system	18Mpa	Bucket Discharge Time	2.0S
Axle
Manufacturer	Feicheng	Main Transmission Type	Double Reduction

The use of a high-reliability hydraulic torque converter and Gearbox to provide superpower aggravated the smooth and high reliability of the dedicated bridge walking
Combine the excavator and the loader into one, and one machine can do more. Fully equipped with all the functions of small excavators and loaders, it is more suitable for operating in a narrow space, convenient and flexible, and working efficiency is increased by more than 30 %.
Mining, and loading functions all lead control, light, and flexible, high operating efficiency.
Humanized design of rotating vibration absorber seat, fully steel-molded glass cab, wider vision, more comfortable driving.
Excavate the lateral sliding mechanism device to make the excavation operation more extensive and more efficient.
The design of the front flip cover greatly improves the maintenance of the entire machine.
A variety of accessories can be selected to complete a variety of construction operations. For use in municipal administration, construction, water Conservancy, highways, tap water, power supply, gardens, and other departments, can be engaged in agricultural construction, pipeline laying, cable laying, landscaping, and other operations

We are committed to providing customers with reasonably priced， high-quality equipment.
Camco adheres to the following service concepts; customer-first and integrity-based, world-class brands, systematization, and standardization of customer service to provide competitive overall service solutions with pre-sales, sales, and after-sales services.
We are devoted and committed to providing durable products and quality service to win the lasting trust and support of our customers.

1. About pricing
The price of this product is the delivery price of LUSAKA company, including VAT;
2. About payment
You can pay by TT or online payment. After the payment is completed, please upload the payment voucher in the system;
3. About delivery
Spot Products: Before picking up the goods, please call the offline store 2 days in advance to confirm whether the stocking is complete, and make an appointment for the pick-up time. On the day of pick-up, pick up the goods at the offline store with the payment voucher;
Customized products: We will send the specific delivery time to your email, please pay attention to check.
4. About returns
Spot Products: within 7 days, the product can be returned if the quality and appearance are intact;
Customized products: when the product functions and parameters are consistent with the customized contract, returns are not allowed;
5. About the warranty
For details, please refer to the quality assurance policy published by our company;
6. About the evaluation
We attach great importance to any evaluation given by each customer. If there is any problem, we will deal with it until you are satisfied. Please do not directly give a medium or poor evaluation without communicating with customer service.
Commitment of CAMCO
1. We provide you with invoices and corresponding offline pre-sales training and after-sales service. Please rest assured to buy!
Note: Since the manufacturer will change the product packaging, origin, or some attachments without any prior notice, the company cannot ensure that the goods received by the customer are completely consistent with the pictures, origins, and attachment descriptions of the mall. If this mall is not updated in time, please understand!
------
●Safety Warning:
Do not use chat tools other than this mall to communicate during the transaction, do not receive suspicious files and do not click on links from unknown sources, and verify the domain name and payment details before payment. Except for online direct payment, the CAMCO company account is the only transfer account. CAMCO will not ask you to provide any bank card, password, or mobile phone verification code if there is a problem with the order! In case of a suspicious situation, please call CAMCO for verification.

●Price Description
1. All prices are the tax-included delivery prices of Lusaka. Pickup in other areas requires an appropriate increase in price according to the transportation situation. If you need to pick up the goods in areas other than LUSAKA, please confirm the transportation price with the customer service staff before placing an order.
2. The fixed price, promotional price, preferential price, and other prices marked in pictures or text on the merchant details page (including the main picture) may be the price when using coupons, full discounts, or specific promotional activities and time periods. For details, please The price, preferential conditions, or event rules on the settlement page shall prevail.

●Declaration Of Rights:
1. All CAMCO product information, customer evaluation, product consultation, netizen discussion, and other content are important business resources, and illegal reprinting and use without permission are prohibited.
Note: The product information on this site comes from the partner. This site does not provide any guarantee and does not assume any legal responsibility
