Disc Mill

SKU:
0.0 (0)
0 Sold
$123.00 $0.00
Contact us if the chosen model price shows 99999USD
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • FFC-series:
    FFC-600 3000r/min
    FFC-500 3000r/min
    FFC-45A 3000r/min
    FFC-37 3600r/min
    FFC-25 5800r/min
    FFC-15 9000r/min
    Please select the information you wantX
Quantity:
Add to Favorites (0)
  • Disc Mill
  • Disc Mill
  • Description
  • About Camco
  • Purchase Notes

    Our FFC series disk mill has multiple functions. At present, there are ten types.
    Models FFC-60, FFC-50, FFC-45A, FFC-37, FFC-23, FFC-20, FFC-19, FFC-18, FFC-16 and FFC-15.
Model Unit 　FFC-600 　FFC-500 FFC—45A FFC—37 FFC—23 FFC—15
Rotational Speed Of r/min 3000 3000 3000 3600 5800 9000
 Main Shaft
Outer Diameter Of The 5Rotator (Including Oblate Gear) mm 600 450 450 370 230 150
Number Of Oblate Gears Of set 8 5 5 4 4 3
 The Rotator
Number Of Knuckle Gears Of set 16 12 12 8 8 3
 The Rotator
Circles Of Square Gears Of circles 2 2 2 2 2 1
The Gear Wheel
Sieve Size mm 0.4, 0.6, 0.8, 1.0, 1.2, 1.5, 1.8, 2.0, 2.5, 3.0, 3.6, 5, 6, 8, 12, 20, 30, 36, 60, 100
Motor Power kw 22-30　 15 11 7.5 3 1.1
Rotational Speed r/min 1450 1450 1450 1450 2840 2840
Dimension mm 1650×1150 1250×900 1150×755 1050×680 800×500 565×305
(Length ×Width × Height ) ×1700　 ×1450　 ×1425 ×1325 ×1000 ×610
Weight kg 386 275 224 158 65 18
Package Size mm 1200×900 970×760 930×670 870×670 635×565 556×271
×1050　 ×750　 ×730 ×658 ×455 ×285
Instructions for use:  The machine should be checked before using the mechanical transmission part is loose and another abnormal phenomenon, the machine's running direction should be consistent with the direction of the arrow.
    When in use, no-load test for 1-2 minutes, to be observed no abnormal phenomenon can feed, feed should flow increase gradually, and observe the motor power supply and operation conditions, the feeding and power balance in normal operation, fixed die cutting plate, work. - such as if the material is too wet, the sticky knot is too big, the effect of powder, should be the material drying or replace the sieve plate thick.
    Change the screen plate only the front cover can be opened, the installation should pay attention to both sides of the front cover handwheel consistent tightness, the front cover, and the casing seal.
    Before the machine is shut down, you should stop feeding and make the machine running 2-3 minutes and then stop, in order to reduce the residual material.
Maintenance and repair:
    Regularly check the bearing, and replace the high-speed butter, in order to ensure the normal operation of the machine.
    Should always check the wearing parts, such as serious abrasion phenomenon to be timely replacement.
    Use of the machine, such as the spindle speed slowing, the motor must be down-regulation, which will enable the machine to achieve the specified speed
strictly prohibited-the metal material flows inside the machine, such as iron nail, iron block.
    After the end of the work, must clean the residual material parts of the machine. Stops for a long time to clean the machine, with a tarpaulin cover
   It is designed compactly with a wonderful appearance: small in size and light in weight, reliable in operation, and easy to maintain. It has a large range of services and proves to be of high quality in crushing.
    With this machine, it is most desirable to crush various coarse grains and fodder, such as corn, soybean, sorghum, dried sweet potato slices, and soybean cake. All of these can be crushed into powder in one stroke without any residue.
    This machine is also popular in the chemical industry, paper-making and medical industry and can be used to crush various kinds of chemical raw materials, exercise beating in paper-making, and process Chinese herbal medicine.
    And can also be used to crush fresh fruit, fresh sweet potato, and soaked soybeans, which contain a great deal of moisture content.
      We are committed to providing customers with reasonably priced， high-quality equipment.
    Camco adheres to the following service concepts; customer-first and integrity-based, world-class brands, systematization, and standardization of customer service to provide competitive overall service solutions with pre-sales, sales, and after-sales services.
    We are devoted and committed to providing durable products and quality service to win the lasting trust and support of our customers.


    We are committed to providing customers with reasonably priced， high-quality equipment.
    Camco adheres to the following service concepts; customer-first and integrity-based, world-class brands, systematization, and standardization of customer service to provide competitive overall service solutions with pre-sales, sales, and after-sales services.
    We are devoted and committed to providing durable products and quality service to win the lasting trust and support of our customers.
