| Model | HBN9110MT |
| Standard platform height | 1070mm |
| Adjustable range | ±300mm |
| Wheelbase | 1550mm |
| Platform width | 2990mm |
| Gooseneck width | 2500mm |
| Steering type | Hydraulic steer |
| Steering angle | 55° |
| Working temperature | -40℃ to 55℃ |
| Steering control system | Manuel & remote control |
| Axle load | 22.5 Ton |
| Tires | 215/75R17.5, 80sets |
| Rim | 6.00-17.5, 80sets |
| Axles | 10 Links(line axles) |
| Power unit | Equipped |
| Power unit brand | Xinchai |
| Tire brand | Double corn |
| Rim Brand | ZHENGXING |
| Axle brand | YUEK brand |
| Cylinder brand | HENGLI |
| Ball valve brand | XIDEFU/pister |
| Quick hatch brand | FASTER |
| Multi-way valve brand | BONDIOLI & PAVESI |
| Hydraulic pipes brand | Eton |
| Hydraulic hatch brand | Eton standard |
This product combines the advantages of the world's advanced hydraulic combined trailers from Germany, France, and other countries and is independently developed, making the product more user-friendly.
The rear of the car adopts an integrated design, with taillights and operability. Warning signs and other equipment are integrated, which is both beautiful and can protect the hydraulic hose and warn the vehicle behind. The frame pipeline is optimized, and all pipelines are fully automatic CNC bending to ensure the consistency of the bend.
The steering system is optimized to make the steering more precise and solve problems such as steering dead center. The trailer hydraulic and air pipes use quick connectors for fast splicing.
The splicing surface of the frame is processed by gantry as a whole, the size is more accurate, and there are no gaps in the splicing surface of the frame. All spliced hoses are numbered clearly and clearly, so customers have a lower error rate during the splicing process of vehicles.
We are committed to providing customers with reasonably priced， high-quality equipment.
