Solar Panel

Name: Solar Panel
Brand: CAMCO MALL
Price: 99999 USD
Availability: InStock

0.0 (0)

0 Sold

$99,999.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

Description
About Camco
Purchase Notes

Main Technical Paraments

STC	STP275-20/	STP270-20/	STP265-20/
STC	Wfw	Wfw	Wfw
Maximum Power At STC (Pmax)	275 W	270 W	265 W
Optimum Operating Voltage (Vmp)	31.2 V	31.1 V	31.0 V
Optimum Operating Current (Imp)	8.82 A	8.69 A	8.56 A
Open Circuit Voltage (Voc)	38.1 V	37.9 V	37.8 V
Short Circuit Current (Isc)	9.27 A	9.15 A	9.02 A
Module Efficiency	16.80%	16.50%	16.20%
Operating Module Temperature	-40 °C to +85 °C
Maximum System Voltage	1000 V DC (IEC)
Maximum Series Fuse Rating	20 A
Power Tolerance	0/+5 W

NOCT	STP275-20/	STP270-20/	STP265-20/
NOCT	Wfw	Wfw	Wfw
Maximum Power at NOCT (Pmax)	200.6 W	198 W	194 W
Optimum Operating Voltage (Vmp)	28.5 V	28.4 V	28.3V
Optimum Operating Current (Imp)	7.05 A	6.97 A	6.86 A
Open Circuit Voltage (Voc)	34.8 V	34.9 V	34.8 V
Short Circuit Current (Isc)	7.5 A	7.42 A	7.32 A

Mechanical Characteristics:

-	Polycrystalline Silicon 6 Inches
Solar Cell
No. of Cells	60 (6 × 10)

Dimensions	1650 × 992 × 35mm (64.96 × 39.1 × 1.4 Inches)

Weight	18.3 kgs (40.3 lbs.)

Front Glass	3.2 mm (0.13 inches) Tempered Glass
Frame	Anodized Aluminium Alloy
Junction Box	IP68 Rated (3 Bypass Diodes)
Output Cables	4.0 mm2 (0.006 Inches2), Symmetrical Lengths (-) 1000mm (39.4 inches) And (+) 1000 mm (39.4 Inches)

Packing Configuration:

Container	20’ GP	40’ HC
Pieces Per pallet	30	30
Pallets Per container	6	28
Pieces Per container	180	840

A solar cell is a device that responds to light and converts light energy into electricity. There are many kinds of materials that can produce photovoltaic effects, such as single-crystal silicon, polycrystalline silicon, amorphous silicon, gallium arsenide, indium selenium copper, and so on. Their power generation principles are basically the same, and the photoelectric power generation process is described by taking crystalline silicon as an example. P-type crystalline silicon can be doped with phosphorus to obtain N-type silicon, forming a P-N junction.
When the light shines on the surface of the solar cell, some photons are absorbed by the silicon material; the energy of the photons is transferred to the silicon atoms, causing the electrons to transition and become free electrons to gather on both sides of the P-N junction to form a potential difference. When the external circuit is connected, under the action of this voltage, there will be a current flowing through the external circuit to generate a certain output power. The essence of this process is the process of converting photon energy into electrical energy.

Advantages

1. High module conversion efficiency

Module efficiency of up to 16.8% is achieved through advanced cell technology and manufacturing capabilities.

2. High PID resistant

Advanced cell technology and qualified materials lead to high resistance to PID.

3. Positive tolerance
of up to 5 W delivers higher output reliablity.

4. Current sorting process

System output is maximized by reducing mismatch losses up to 2% with modules sorted & packaged by amperage.

5. Extended wind and snow load tests

Module certified to withstand extreme wind (3800 Pascal) and snow loads (5400 Pascal) *.

6. Withstanding harsh environment

Reliable quality leads to better sustainability even in harsh environments like deserts, farms, and coastlines.
