Lugong wheel loader LG series

SKU:
0.0 (0)
0 Sold
$13,025.00 $0.00
The price above is FOB China price.
Please contact our local branches in Africa for precise prices.
If the price is $99999, please contact us for precise prices.
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • LG-series:
    LG930 1.8T 0.9m³
    LG938 2T 1m³
    LG939 2.2T 1m³
    LG940 2.2T 1m³
    LG946 2.5T 1.3m³
    Please select the information you wantX
  • Attachments:
    Please select
    Please select
    Wood grapple[ + $350.00 ]
    grass grapple[ + $300.00 ]
    4 in 1 bucket[ + $750.00 ]
  • Total extras:$0.00
Quantity:
  • Lugong wheel loader LG series
  • Lugong wheel loader LG series
  • Lugong wheel loader LG series
  • Lugong wheel loader LG series
  • Lugong wheel loader LG series
  • Description
  • About Camco
Model  LG930 LG938 LG939 LG940 LG946
Main Technical Parameters
Bucket Capacity  0.90m³ 1.0m³ 1.0m³ 1.0m³ 1.3m³
Rated Load(kg) 1800 2000 2200 2200 2500
Machine Weight(kg) 3500 4500 4950 5750 7200
Overall Dimension (mm) 5340X1900X2750 6000X2050X2950 6200X2150X2950 6250X2150X2950 6540X2150X3100
Wheelbase  (mm) 2320 2490 2500 2710 2710
Wheel Track (mm) 1500 1690 1680 1680 1680
Bucket Width (mm) 1900 2000 2200 2200 2400
Max. dumping Height (mm) 3100 3500 3500 3800 3800
Max. dumping Height (mm) 650 750 800 800 650
Turning Radius (mm) 4900 4500 4500 6000 6000
Min. ground Clearance (mm) 230 320 380 380 428
Engine
Model  Weichai 4102 Sida 4102 Turbo Yuchai 4105 Turbo Yuchai 4105 Turbo Yuchai 4105 Turbo
Pattern  In-Line, 4 Cylinder In-Line, 4 Cylinder In-Line, 4 Cylinder In-Line, 4 Cylinder In-Line, 4 Cylinder
Rated Power/Speed 65KW/2400 76KW/2400 85KW/2400 85KW/2400 92KW/2400
Weight(kg) 240 320 360 360 -
Tyre 20.5-16 16/70-20 16/70-24 16/70-24 17.5-25
Transmission
Type Hydraulic Torque Converter Hydraulic Torque Converter Hydraulic Torque Converter Hydraulic Torque Converter Hydraulic Torque Converter
Pattern Automatic Automatic Automatic Automatic Automatic
Gear Shift Double H/L Double H/L Double H/L Double H/L Double H/L
Axle AWD, Small Hub Reduction AWD, LG2.0 Hub Reduction AWD,LG2.5 Hub Reduction AWD,LG2.5 Hub Reduction AWD,LG2.5 Hub Reduction
Working Hydraulic System
Operating Type Mechanical Single Joystick Mechanical Single Joystick Mechanical Single Joystick Mechanical Single Joystick Mechanical Single Joystick
Lifting Time(s) 5 5 6.5 6.5 6.5
Falling Time(s) 4 4 5.5 5.5 5.5
Braking System
Service Brake Air Hydraulic Disc Brake Air Hydraulic Disc Brake Air Hydraulic Disc Brake Air Hydraulic Disc Brake Air Hydraulic Disc Brake
Parking Brake Hand Operated  Hand Operated  Hand Operated  Hand Operated  Hand Operated
Optional Configuration Engine: Sida 493 Turbo / 58kw; A/C, Cabin Heater, Forklift; Pallet Fork, Log Grapple, Grass Fork, etc. Engine: Weichai4102 Turbo / 76kw
Optional Configuration: Yuchai 498 Turbo/73 kw
Yuchai 4102 Turbo/78 kw
Yunnei 76kw
 A/C, Cabin Heater, Forklift
Pallet Fork, Log Grapple, Grass Fork, etc.
Optional Configuration:
A/C, Cabin Heater, Forklift
Pallet Fork, Log Grapple, Grass Fork, etc.
Optional Configuration: A/C, Cabin Heater, Forklift
Engine: YC6J125-T302/92kw(EUR III)
Pallet Fork, Log Grapple, Grass Fork, etc.
Optional Configuration: Engine: YN27 / 42kw
Cabin Heater, Forklift
Pallet Fork, Log Grapple, Grass Fork, etc.

  Wheel loader is a central articulated frame type that makes it smaller on the turning radius of the wheel loader, also making it more flexible and stable. It’s more suitable for the narrow place operating.
    The working pump and the steering pump for the wheel loaders' double pump confluence make the working of the loaders more efficient and also make our wheel loaders to be more economical loaders amount.

     According to the requirements of users or different working conditions, various working devices such as coal buckets, wooden forks, grain buckets, and grass forks can be selected.


We are committed to providing customers with reasonably priced, high-quality equipment.
CAMCO adheres to the following service concepts: customer-first and integrity-based, world-class brands, systematization, and standardization of customer service to provide competitive overall service solutions with pre-sales, sales, and after-sales services.
We are devoted and committed to providing durable products and quality service to win the lasting trust and support of our customers.
