Lugong wheel loader T-series

SKU:
0.0 (0)
6 Sold
$9,912.00 $0.00
The price above is FOB China price.
Please contact our local branches in Africa for precise prices.
If the price is $99999, please contact us for precise prices.
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • T-series:
    T920 1.5T 0.6m³
    T930 1.8T 0.9m³
    T933 1.8T 0.9m³
    T938 1.8T 1m³
    Please select the information you wantX
  • Attachments:
    Please select
    Please select
    Wood grapple[ + $350.00 ]
    grass grapple[ + $300.00 ]
    4 in 1 bucket[ + $750.00 ]
  • Total extras:$0.00
Quantity:
  • Lugong wheel loader T-series
  • Lugong wheel loader T-series
  • Lugong wheel loader T-series
  • Lugong wheel loader T-series
  • Description
  • About Camco

Model  T920 T930 T933 T938
Main technical parameters
Bucket capacity  0.60m³ 0.90m³ 0.90m³ 1m³
Rated load  1500kg 1800kg 1800kg 1800kg
Machine weight 2950kg 3500kg 4340kg 4950kg
Overall dimension (mm) 4940X1800X2750 5340X1900X2750 5640X2000X2850 6220X2000X2920
Wheelbase  2150mm 2320mm 2330mm 2530 mm
Wheel track  1500mm 1500mm 1500mm
Bucket width  1800mm 1900mm 2000mm
Max. dumping height  2900mm 3100mm 3500mm 3900mm
Max. dumping height  740mm 650mm 700mm 750mm
Turning radius  4700mm 4900mm 4900mm 4750mm
Min. ground clearance  260mm 230mm 230mm
Engine
Model  Sida490 Weichai4102 turbo Huafeng4102 HuafengZHBZG1
Pattern  in-line, 4 cylinder in-line, 4 cylinder
Rated power/speed  42KW/2400 65KW/2400 65/2400
Weight  230kg 240kg 340kg
Tyre 20.5-16 20.5-16 16/60-20 16/70-20
Transmission
Type hydraulic torque converter hydraulic torque converter 265 torque converter
Pattern automatic automatic
Gear shift double H/L double H/L double H/L
Axle AWD, small hub reduction  AWD, small hub reduction AWD, small hub reduction
Working hydraulic system
Operating type mechanical single joystick  mechanical single joystick mechanical single joystick
Lifting time 5S 5S 5S
Falling time 3S 4S 4S
Braking system
Service brake air hydraulic disc brake air hydraulic disc brake air hydraulic disc brake  air hydraulic disc brake
Parking brake hand operated  hand brake hand brake hand brake
Optional configuration optional configuration: engine: YN27 / 42kw
cabin heater, forklift
pallet fork, log grapple, grass fork, etc.
optional configuration: engine: Sida 493 turbo / 58kw
A/C, cabin heater, forklift
pallet fork, log grapple, grass fork, etc
optional configuration: engine: Sida 493 turbo / 58kw
A/C, cabin heater, forklift
pallet fork, log grapple, grass fork, etc
optional configuration: engine: Sida 493 turbo / 58kw
A/C, cabin heater, forklift
pallet fork, log grapple, grass fork, etc

Our wheel loaders adopt the hydraulic control steering and power transmission shifting system which makes the operating of the wheel loaders more flexible and stable. In order to make the wheel loaders more reliable, our engineers make the special design on the chassis frames and the working system.
    The design for the wheel loader is a central articulated frame type makes it smaller on the turning radius of the wheel loader, also making it more flexible and stable. It’s more suitable for the narrow place operating.
    The working pump and the steering pump for the wheel loaders' double pump confluence make the working of the loaders more efficient and also make our wheel loaders to be more economical loaders amount.

  According to the requirements of users or different working conditions, various working devices such as coal buckets, wooden forks, grain buckets, and grass forks can be selected.
We are committed to providing customers with reasonably priced, high-quality equipment.
CAMCO adheres to the following service concepts: customer-first and integrity-based, world-class brands, systematization, and standardization of customer service to provide competitive overall service solutions with pre-sales, sales, and after-sales services.
We are devoted and committed to providing durable products and quality service to win the lasting trust and support of our customers.
