Lugong wheel loader T-series

Name: Lugong wheel loader T-series
Brand: CAMCO MALL
Price: 9912 USD
Availability: InStock

0.0 (0)

6 Sold

$9,912.00

The price above is FOB China price.
Please contact our local branches in Africa for precise prices.
If the price is $99999, please contact us for precise prices.

Received successfully

Coupon Code

CONTINUE SHOPPING

Quantity:

Add to Favorites (1)

Description
About Camco

Model	T920	T930	T933	T938
Main technical parameters
Bucket capacity	0.60m³	0.90m³	0.90m³	1m³
Rated load	1500kg	1800kg	1800kg	1800kg
Machine weight	2950kg	3500kg	4340kg	4950kg
Overall dimension (mm)	4940X1800X2750	5340X1900X2750	5640X2000X2850	6220X2000X2920
Wheelbase	2150mm	2320mm	2330mm	2530 mm
Wheel track	1500mm	1500mm	1500mm
Bucket width	1800mm	1900mm	2000mm
Max. dumping height	2900mm	3100mm	3500mm	3900mm
Max. dumping height	740mm	650mm	700mm	750mm
Turning radius	4700mm	4900mm	4900mm	4750mm
Min. ground clearance	260mm	230mm	230mm
Engine
Model	Sida490	Weichai4102 turbo	Huafeng4102	HuafengZHBZG1
Pattern	in-line, 4 cylinder	in-line, 4 cylinder
Rated power/speed	42KW/2400	65KW/2400	65/2400
Weight	230kg	240kg	340kg
Tyre	20.5-16	20.5-16	16/60-20	16/70-20
Transmission
Type	hydraulic torque converter	hydraulic torque converter	265 torque converter
Pattern	automatic	automatic
Gear shift	double H/L	double H/L	double H/L
Axle	AWD, small hub reduction	AWD, small hub reduction	AWD, small hub reduction
Working hydraulic system
Operating type	mechanical single joystick	mechanical single joystick	mechanical single joystick
Lifting time	5S	5S	5S
Falling time	3S	4S	4S
Braking system
Service brake	air hydraulic disc brake	air hydraulic disc brake	air hydraulic disc brake	air hydraulic disc brake
Parking brake	hand operated	hand brake	hand brake	hand brake
Optional configuration	optional configuration: engine: YN27 / 42kw cabin heater, forklift pallet fork, log grapple, grass fork, etc.	optional configuration: engine: Sida 493 turbo / 58kw A/C, cabin heater, forklift pallet fork, log grapple, grass fork, etc	optional configuration: engine: Sida 493 turbo / 58kw A/C, cabin heater, forklift pallet fork, log grapple, grass fork, etc	optional configuration: engine: Sida 493 turbo / 58kw A/C, cabin heater, forklift pallet fork, log grapple, grass fork, etc

Our wheel loaders adopt the hydraulic control steering and power transmission shifting system which makes the operating of the wheel loaders more flexible and stable. In order to make the wheel loaders more reliable, our engineers make the special design on the chassis frames and the working system.

The design for the wheel loader is a central articulated frame type makes it smaller on the turning radius of the wheel loader, also making it more flexible and stable. It’s more suitable for the narrow place operating.
The working pump and the steering pump for the wheel loaders' double pump confluence make the working of the loaders more efficient and also make our wheel loaders to be more economical loaders amount.
　　According to the requirements of users or different working conditions, various working devices such as coal buckets, wooden forks, grain buckets, and grass forks can be selected.

We are committed to providing customers with reasonably priced, high-quality equipment.
CAMCO adheres to the following service concepts: customer-first and integrity-based, world-class brands, systematization, and standardization of customer service to provide competitive overall service solutions with pre-sales, sales, and after-sales services.
We are devoted and committed to providing durable products and quality service to win the lasting trust and support of our customers.
